3M MNG18-47PX-A Pin Terminal, Red, Nylon, 0.075 in Pin Dia
UPC: 051128588451 | Harmonization / Schedule B : 8536.90.4000
Country of Origin: Taiwan | Shipping Weight: 0.21 lbs
Original price
$246.32
-
Original price
$246.32
Original price
$246.32
$246.32
-
$246.32
Current price
$246.32
Pin Terminal, Contact Finish Tin, Contact Material Copper, Insulation Color Red, Insulation Coverage Partial Coverage, Insulation Material Nylon, Maximum Operating Temperature 221 Degrees F, Maximum Voltage 600 V, Minimum Wire Size 22 AWG, Maximum Wire Size 18 AWG, Pin Diameter 0.075 in, Pin Length 0.47 in, RoHS Compliant Yes, Seam Style Butted, Standards CSA Certified, UL Listed, Termination Style Crimp, Barrel Inside Diameter 0.08 in, Barrel Outside Diameter 0.17 in
| Maximum Wire Size | 18 AWG |
|---|---|
| Minimum Wire Size | 22 AWG |
| Overall Length | 0.9 in |
| Pin Length (In.) | 0.47 |
| Barrel Inside Dia. | 0.08 in |
| Pin Diameter | 0.075 in |
| Barrel Inside Diameter | 0.08 in |
| Pin Length | 0.47 in |
| Barrel Outside Diameter | 0.17 in |
| Stud Size | 0.075 in |
| Wire Rope Length | 0.9 in |
| Length | 0.9 in |
| Terminal Shape | Pin |
| Termination Style | Crimp Termination Only |
| Insulation Color | Red |
| Insulation Coverage | Partial Coverage |
| Insulation Type | Nylon |
| Contact Material | Copper |
| Maximum Voltage | 600 V |
| Minimum Operating Temperature | -40 Degrees F |
| Maximum Operating Temperature | 221 Degrees F |
| Standards | CSA Certified, UL Listed |
| Wire Range | 22 to 18 AWG |
| Max. Voltage | 600 V |
| Terminal Connection | Crimp |
| Max. Temp. | 221 Degrees F |
| Seam | Brazed |
| Connection Type | Crimp |
| Connection Material | Copper |
| Terminal Type | Pin |
| Special Features | Funnel-Designed, Seamless Brass Sleeve Offers Easy Insertion of Wires, Provides Quick Connection for Set Screws or Clamps That are Used to Make Electrical Contact |
| Compatible with Product Type | Copper Wires |
| RoHS Compliant | Yes |
| Seam Style | Butted |
| Barrel Style | Insulation Grip |
| Insulation Material | Nylon |
| Contact Finish | Tin |
| Insulation Dia | 0.17 Inch |
| Country of Origin | Taiwan, Province of China |
