Anvil 0308017805 Metal Pipe Flange, 12 in, Female NPT Blind, Cast Iron, Flat Flange, Class 125, Black
Original price
$1,603.73
-
Original price
$1,603.73
Original price
$1,603.73
$1,603.73
-
$1,603.73
Current price
$1,603.73
Flange, Flat, 12 in Nominal Pipe Size, Flanged, 19 in Flange Outside Diameter, 19 in Overall Length, Cast Iron, Plain, A197, Class Class 125, For Pipe Schedule Not Applicable, 175 psi Maximum Operating Pressure, -20 Degrees to 150 Degrees F, Number of Bolt Holes 12, Not Applicable Bolt Circle Diameter, Not Applicable Bolt Hole Diameter
| Specific Fitting Shape | Blind Flange |
|---|---|
| Fitting Connection Type | Flanged |
| Pipe Fitting Material | Cast Iron |
| Class | Class 125 |
| Standards | UL: FM Approved: ASME B16.4 |
| Temp. Range | -20 Degrees to 150 Degrees F |
| Fitting Schedule/Class | Class 125 |
| Number of Holes | 12 |
| Specific Pipe Fitting Shape | Blind Flange |
| Basic Pipe Fitting Material | Metal |
| Max. Pressure | 175 psi@-20 Degrees to 150 Degrees F |
| Pipe Fitting Schedule/Class | Class 125 |
| Pipe Fitting Connection Type | Flanged |
| Saturated Steam Pressure | 125 psi |
| Basic Pipe Fitting Shape | Flange |
| Application | Fire Protection, Non-Potable Water |
| Maximum Operating Pressure | 175 psi |
| Number of Bolt Holes | 12 |
| Type | Faced & Drilled Threaded |
| Country of Origin | United States |
