Apollo 6210801 Ball Cone Spring Check Valve Single Flow, Stainless Steel, FNPT x FNPT

Apollo™, 6210801, In-Line Check Valve, Series: 62-100, 2 in Nominal, FNPT End Style, 400 psi CWP Pressure, 350 deg F, No Low Lead Compliance, 81 gpm Flow Rate, Spring Actuator, 6 in Inlet to Outlet Length, Stainless Steel Body, Domestic

The 62-100 Series is uniquely suited for applications in corrosive environments, including chemical processing, pulp and paper and other process industries. The rugged stainless steel body and RPTFE ball check provide reliable, patented protection against reverse flow.

Connection Type	FNPT
Connection	FNPT
Body Material	Stainless steel
UPC	670750633607
Material of Construction	Stainless Steel
Min. Temp. - Valves	33 Degrees F
Mechanism and Body Design	Inline Ball Cone
Connection Type - Check Valves	FNPT x FNPT
Item - Check Valves	Check Valve
Sub-Category	Stainless Steel
Max. Temp.	350 Degrees F
Cracking Pressure	0.5 psi
Application - Valves	General Purpose
Seat Material	RPTFE
Max. Temp. - Valves	180 Degrees F
Seal Material - Check Valves	EPDM
Spring Material	316 Stainless Steel
Mounting Orientation - Check Valves	Horizontal, Vertical
Max. Steam Pressure - Valves	150 psi WSP
Max. Water Pressure - Valves	400 psi
Spring Material - Check Valves	316 Stainless Steel
Body Material - Valves	Stainless Steel
Max. Steam Pressure	150 psi SWP
Max. Water Pressure	400 psi Non Shock CWP
Seat Material - Check Valves	RPTFE
Cracking Pressure - Check Valves	0.5 psi
Flow Design	Single
Max. Pressure	400 psig CWP
Mounting Position	Vertical or Horizontal
Seal Material	EPDM
Mounting Orientation	Horizontal, Vertical
Valve Body Material	Stainless Steel
