Approved Vendor G15-60F-12X12 PTFE Sheet, 0.0625 in Thick, 12 in x 12 in, White, Translucent
Original price
$68.18
-
Original price
$68.18
Original price
$68.18
$68.18
-
$68.18
Current price
$68.18
PTFE Sheet, PTFE, Grade Standard, Plastic Length 12 in, Plastic Width 12 in, Plastic Thickness 0.0625 in, White, Plastic Clarity Translucent, Tensile Strength 1,500 psi, Impact Strength 3 ft-lb/in, Friction Coefficient 0.08, Water Absorption 0.01 Percent, Temperature Range -350 Degrees to 550 Degrees F, Plastic Density 13.24 lb/cu ft, Plastic Hardness 55D
| Plastic Material | PTFE |
|---|---|
| Plastic Color | White |
| Max. Temp. (F) | 500 Degrees F |
| Min. Temp. (F) | -400 Degrees F |
| Color | White |
| Plastic Properties | Abrasion Resistant, Chemical/Corrosion Resistant, Electrical Applications, FDA Approved, Flame Retardant, Impact Resistant, Moisture Resistant, Non-Friction Surface, Oil Resistant, UV Tolerant, Wear Material |
| Tensile Strength | 1,500 psi |
| Material Type | Standard Grade |
| Standards | AMS 3652, MIL-P-22241 |
| Impact Strength | 3 ft-lb/in |
| Plastic Grouping | Sheet Stock |
| Material Color Family | White |
| Thickness Tolerance | +/-0.006 in |
| Operating Temp. Range | -400 Degrees to 500 Degrees F |
| Material | PTFE |
| UV Resistant | Yes |
| Plastic Hardness Rating | Medium Soft |
| Plastic Density | 13.24 lb/cu ft |
| Friction Coefficient | 0.08 |
| Plastic Thickness Tolerance | +/-0.006 in |
| Shape | Square |
| Tensile Strength Rating | Poor |
| Plastic Hardness | 55D |
| Temperature Range | -350 Degrees to 550 Degrees F |
| Impact Strength Rating | Good |
| Plastic Clarity | Translucent |
| Wear Factor | Excellent |
| Weight | 0.066 lb |
| Corrosion and Chemical Resistance | Excellent |
| Machinability | Not Rated |
| Maximum Temperature | 550 Degrees F |
| Grade | Standard |
| Minimum Temperature | -350 Degrees F |
| Water Absorption Rating | Excellent |
| Backing Type | No Backing |
| Friction Rating | Very Slippery |
| Water Absorption | 0.01 % |
| Wear Rate | 3.40 x 10^-4 cu mm/N-m |
| Flexural Modulus | 0.04 GPa |
| Shore Hardness | 55 Shore D |
| Scratch-Resistant | Not Scratch-Resistant |
| Fabrication | Molded |
| UV-Resistant | UV-Resistant |
| Product Form | Sheet |
| Light Transmission | 9 % |
| Metal Detectable | Not Metal Detectable |
| Coefficient of Thermal Expansion | 13 x 10^-5 |
| Dielectric Strength | 80 kV/mm |
| Product Type | Plastic Sheet |
| Elongation | 200 % |
| Rockwell Hardness | 50 HRR |
| Static-Resistant | Not Static-Resistant |
| FDA Compliance | Not FDA Compliant |
| Country of Origin | United States |
