Approved Vendor RW3LZ29 Hose Clamp, Zinc-Plated Steel Band, Smooth, External Hex, 1 3/4 in – 2 3/64 in Dia., 7/8 in Band Wd
UPC: 190735481097 | Harmonization / Schedule B : 7326.90.8688
Country of Origin: China | Shipping Weight: 0.6 lbs
Original price
$7.25
-
Original price
$7.25
Original price
$7.25
$7.25
-
$7.25
Current price
$7.25
Hose Clamp, Band Material Steel, Band Material Finish Zinc-Plated, Band Thickness 0.256 in, Band Width 7/8 in, Clamp Maximum Inside Diameter 2 3/64 in, Clamp Minimum Inside Diameter 1 3/4 in, Install Torque 27 ft-lb, Screw Material Steel, Screw Material Finish Zinc-Plated, Clamp Type Double-Bolt Clamp, Fastener Housing Material Zinc-Plated Steel, For Use On Compressor Hoses, Low Pressure Couplings, Pneumatic Couplings, Hex Size 10 mm
| Min. Hose Outside Dia. (In.) | 1 3/4 in |
|---|---|
| Hose Inside Dia. (In.) | 1 1/4 in |
| Max. Hose Outside Dia. (In.) | 2 3/64 in |
| Hex Size | 10 mm |
| Band Width | 7/8 in |
| Band Thickness | 0.256 in |
| For Maximum Outside Diameter | 2 3/64 in |
| For Minimum Outside Diameter | 1 3/4 in |
| Clamp Minimum Inside Diameter | 1 3/4 in |
| Clamp Maximum Inside Diameter | 2 3/64 in |
| MFR # | 3LZ29 |
| Zoro # | G2653996 |
| UPC # | 190735481097 |
| Country of Origin | China |
| Clamp Type | Double-Bolt Clamp |
| For Use With | Low Pressure Couplings |
| Torque (Foot-Pounds) | 27 ft-lb |
| Material of Construction | Carbon Steel |
| Type | Bolt-Close Clamp |
| Screw Material Finish | Zinc-Plated |
| Maximum Operating Temperature | 150 Degrees F |
| Application | Air Pressure Applications |
| Grade | General Purpose |
| Band Material Finish | Zinc-Plated |
| Screw Material | Steel |
| Band Type | Smooth |
| For Use On | Compressor Hoses, Low Pressure Couplings, Pneumatic Couplings |
| For Environment | Agicultural, Drilling, Jackhammer, Mining, Washdown |
| Drive Type | External Hex |
| Maximum Torque | 27 ft-lb |
| Band Material | Steel |
| Install Torque | 27 ft-lb |
| Fastener Housing Material | Zinc-Plated Steel |
| Reusable Clamp | Yes |
| Features | 2 Bolt |
| Minimum Operating Temperature | -20 Degrees F |
| Country of Origin | China (subject to change) |
