Crydom DR-ODC5 Output Module DIN-Rail & Surface Relay Mounting, 4 Pins, 4 to 8V DC Input

Output Module, Contact Form SPST-NO, Output Current 3 A, Input Voltage 4 to 8V DC, Output Voltage 5 to 48V DC, Number of Pins 4, Mounting Style DIN Rail, Body Depth 0.69 in, Body Height 1.77 in, Body Width 1.96 in, Case Color Black (AC Output); Red (DC Output), Features Barrier Strips Accept 14 to 28 AWG Wire, Zero Voltage Turn-On for AC Modules, Isolation Voltage 4kV, Output Type Digital, Overall Depth 2.32 in, Standards CE Certified, CSA Certified, UL Listed, Status Indicator LED Indicator

Special Features	LED Indicator
Case Color	Black (AC Output); Red (DC Output)
Max. Output Amps w/Heat Sink	3
Output or Controlled Voltage Range	5 to 48V DC
Voltage Output	5 to 48VDC
Max. Output Amps - Module	3.0 A
Standards	CE Certified, CSA Certified, UL Listed
Item - Relay	Output Module
Type of Output	Solid State
Number of Pins - Relay	4
Mounting Style	DIN Rail
Mounting - Relay	DIN Rail
Input or Control Voltage	4 to 8V DC
Input Voltage	4 to 8V DC
Contact Form - Relay	SPST-NO
Features	Barrier Strips Accept 14 to 28 AWG Wire, Zero Voltage Turn-On for AC Modules
Contact Form	SPST-NO
Output Type	Digital
Output Voltage	5 to 48V DC
Number of Pins	4
Isolation Voltage	4kV
Output Current	3 A
Status Indicator	LED Indicator
