Eaton ED3125 Molded Case Circuit Breaker, ED Series, 125A, 3-Pole, 240V AC, 65kA AIR, Thermal Magnetic
Original price
$2,620.13
-
Original price
$2,620.13
Original price
$2,620.13
$2,620.13
-
$2,620.13
Current price
$2,620.13
Molded Case Circuit Breaker, 125 A Amps, AC Voltage Rating 240V AC, Max. AIR Rating 65kA at 240V AC, Series ED, High Amp Trip Setting 225 A, Low Amp Trip Setting 15 A, Circuit Breaker Type Standard, Number of Poles 3, DC Voltage Rating 125V DC, Terminal Connection Load Side Lug, Trip Type Thermal Magnetic, Phase Three, Instantaneous Trip Fixed, Phase Connection ABC, Frame Size 225A/F
| Series | ED |
|---|---|
| Amps | 125A |
| Number of Poles | 3 |
| AC Voltage Rating | 240V AC |
| Circuit Breaker Type | Standard |
| Phase | 3 |
| Circuit Breaker Actuator | Toggle |
| Circuit Breaker Mounting Style | Free Standing |
| Max. AIR Rating | 65kA at 240V AC |
| Trip Type | Thermal Magnetic |
| Instantaneous Trip | Fixed |
| Terminal Connection | Lugs |
| Phase Connection | ABC |
| DC Voltage Rating | 125V DC |
| High Amp Trip Setting | 225 A |
| Standards | CSA Certified, IEC Rated, UL Listed |
| Low Amp Trip Setting | 15 A |
| Frame Type | Complete Breaker |
| Interrupt Rating | 65 kA at 240V AC |
| Max. Operating Temp. | 158 Degrees F |
| Min. Operating Temp. | -4 Degrees F |
| Certifications | UL Listed |
| Country of Origin | Dominican Republic |
