Eaton FD3050 Molded Case Circuit Breaker 50 A Amps, 65kA at 240/277V AC, Fixed, ABC, Load Side Lug, Std
Original price
$2,020.19
-
Original price
$2,020.19
Original price
$2,020.19
$2,020.19
-
$2,020.19
Current price
$2,020.19
Molded Case Circuit Breaker, 50 A Amps, AC Voltage Rating 600V AC, Max. AIR Rating 65kA at 240/277V AC, For Use With Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse, Series FD, High Amp Trip Setting 225 A, Low Amp Trip Setting 15 A, Circuit Breaker Type Standard, Number of Poles 3, DC Voltage Rating 250V DC, Terminal Connection Load Side Lug, Trip Type Thermal Magnetic, Phase Three, Instantaneous Trip Fixed, Phase Connection ABC
| Series | FD |
| Amps | 50A |
| Number of Poles | 3 |
| AC Voltage Rating | 600V AC |
| Circuit Breaker Type | Standard |
| Phase | 3 |
| Circuit Breaker Actuator | Toggle |
| Circuit Breaker Mounting Style | Free Standing |
| Max. AIR Rating | 65kA at 240/277V AC |
| Trip Type | Thermal Magnetic |
| Instantaneous Trip | Fixed |
| Terminal Connection | Load Side Lug |
| Phase Connection | ABC |
| DC Voltage Rating | 250V DC |
| High Amp Trip Setting | 225 A |
| Low Amp Trip Setting | 15 A |
| For Use With | Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse |
| Standards | CSA Certified, IEC Rated, UL Listed |
| Interrupt Rating | 65 kA at 240V AC |
| Frame Type | Complete Breaker |
| Min. Operating Temp. | -4 Degrees F |
| Max. Operating Temp. | 158 Degrees F |
| Terminals | Load side |
| Product Name | Eaton Series C complete molded case circuit breaker |
| Frequency Rating | 50/60 Hz |
| Certifications | UL Listed |
| Frame | F |
| Mounting | Free Standing |
