Hayward TBH2250A0SE0000 Manual Two-Way Ball Valve 2 1/2 in, CPVC, Straight, True-Union Socket

Manual Two-Way Ball Valve, Body Material CPVC, For Media Corrosive Chemicals, Water, Valve Construction Three-Piece, Nominal Valve Size 2 1/2 in, Valve Body Style Straight, 3-A Standard Compliance Not Rated, Average Surface Roughness (Ra) Not Applicable, Maximum Pressure - Operating 235 psi, Maximum Pressure - Steam Not Applicable, Maximum Pressure - Combustible Gas Not Rated, Vacuum Service Rating Not Rated, Ball Material CPVC, Ball Port Style Full Port, Handle - Locking

Body Material	CPVC
Body Style	True Union
Body Seal Material	EPDM
Temp. Range	235 PSI @ 70 Degrees F 16 Bar @ 21 Degrees C Non-Shock
Standards	ASTM D1784 Cell Class 23447, ASTM D4101 Cell Class 85580, NSF/ANSI 372
Handle Type	Tee
Valve Structure	1-Piece
Max. Pressure	235 psi
Ball Material	CPVC
Item	Manual Two-Way Ball Valve
Special Features	Actuator Compatible
Handle Material	Glass-Filled Polypropylene
Stem Material	CPVC
Port	Full
Stem Type	Blowout Resistant
Seat Material	PTFE
Features	Double O-Ring Stem Seals, Easy Replacement for Existing Hayward TB Series, Permanent Laser Markings Eliminates Labels, Standard Lock-Out Plate and Lock-Out/Tag-Out for upto 4 Locks, System Friendly 'Molded-In' Footpad for Skid or Panel Mount, System2(TM) Sealing Technology Seat Carrier Design for Sizes upto 2 in/DN50-Patent Pending
Seal Material	EPDM
Connection Type	Socket x Socket
Handle - Locking	Locking
For Media	Corrosive Chemicals, Water
Connection Gender - Side 2	Female
Valve Body Style	Straight
Vented Ball Valve	Non-Vented
Maximum Pressure - Operating	235 psi
3-A Standard Compliance	Not Rated
Ball Port Style	Full Port
Included Mounting	ISO 5211 Actuator Mounting Pad
Maximum Pressure - Combustible Gas	Not Rated
Connection Type - Side 1	True-Union Socket
Operating Temperature - Maximum	190 Degrees F
Color - Valve Handle	Red
Connection Type - Side 2	Socket
Valve Ways	2-Way
Vacuum Service Rating	Not Rated
Manufacturer Warranty	3 yr
Coefficient of Volume (Cv)	340
Operating Temperature - Minimum	34 Degrees F
NSF Certifications for Food and Drinking Water	NSF 61
Valve Construction	Three-Piece
Connection Gender - Side 1	Female
