Hubbell HBL8200I Receptacle Duplex, 5-15R, 15 A, 125V AC, Ivory, 2 Poles, Hospital Grade Fed. Spec., Screw Terminals
Original price
$44.42
-
Original price
$44.42
Original price
$44.42
$44.42
-
$44.42
Current price
$44.42
Receptacle, Connection Orientation Straight, Cover Type No Cover, Current Rating 15 A, GFCI No, Grounding Grounded, Housing Color Ivory, Housing Material Thermoplastic, Mount Type Flush, NEMA Enclosure Rating 1, NEMA Receptacle Configuration 5-15R, Number of Gangs 1, Number of Poles 2, Number of Wires 3, Phase Single, Polarized Yes, Receptacle Type Duplex, Standards CSA Certified C22.2 No. 42 File 285, Federal Specification W-C-596, NEMA WD-6, UL 498 File E2186, Voltage Rating 125V AC
| Item - Plugs and Receptacles | Receptacle |
| Outlet Type - Plugs and Receptacles | Standard Duplex |
| Application Environment | Heavy Use Hospital Grade |
| Mounting Type - Plugs and Receptacles | Flush |
| Amps - Plugs and Receptacles | 15 A |
| Voltage - Plugs and Receptacles | 125V AC |
| NEMA Receptacle Configuration - Plugs and Receptacles | 5-15R |
| Surge Suppression | No |
| Tamper Resistant | No |
| Material | Thermoplastic |
| Wiring Method | Back, Side |
| Wiring Method - Plugs and Receptacles | Back and Side |
| Mounting Type | Flush |
| Weather Resistant - Plugs and Receptacles | No |
| Power Indicator | No |
| Outlet Type | Duplex |
| Color | Ivoire |
| HP | 1/2 hp |
| Item | Traditional Duplex |
| Corrosion Resistant | No |
| Amps | 15 |
| Number of Wires | 3 |
| Phase | Single Phase |
| NEMA Configuration | 5-15 |
| Standards | CSA Certified C22.2 No. 42 File 285, Federal Specification W-C-596, NEMA WD-6, UL 498 File E2186 |
| Number of Poles | 2 |
| Weather Resistant | No |
| IP Rating | IP20 |
| Voltage | 125VAC |
| Color - Plugs and Receptacles | Ivory |
| Number of Gangs | 1 |
| Sub-Category | Duplex Receptacles |
| Amperage | 15 A |
| Mounting Hardware Material | Screw Mounting |
| Number Of Wires | 3-Wire |
| Operating Temperature | Maximum continuous 75°C and minimum -40°C without Impact |
| Current Rating | 15 A |
| Connectivity | Back and Side Wired Screw Terminals |
| Carton Quantity | 10 |
| Dielectric Strength | Withstands 2,000V minimum |
| Type | Receptacle |
| Maximum Horsepower | 0.5 |
| Application | Extra Heavy Duty Hospital Grade |
| Style | Finder Groove Face |
| Wattage | 1875 W |
| Series | Hospital Grade |
| Brand | Hubbell Wiring Device-Kellems |
| Nema Rating | 5-15R |
| Voltage Rating | 125 V |
| Number Of Poles | 2-Pole |
| Environmental Rating | Indoor Dry Unless Protected By Additional Means |
| NEMA Receptacle Configuration | 5-15R |
| Wire Connection Types | Screw Terminals |
| For Location | Indoor |
| Number of Poles & Wires | 2 Pole / 3 Wire |
| Flange Type | Non-Flanged |
| Housing Material | Thermoplastic |
| NEMA Enclosure Rating | 1 |
| Cover Type | No Cover |
| Wire Connection Type | Screw Terminals |
| Contact Material | Nickel-Plated Brass |
| Receptacle Type | Duplex |
| Connection Orientation | Straight |
| Polarized | Yes |
| GFCI | No |
| Additional Electrical Protection | Standard Protection |
| Mount Type | Flush |
| Additional Electrical Protections | Standard Protection |
| Includes | Grounding Clip, Mounting Hardware, Wall Plate or Weatherproof Cover |
| UL 94 Flammability Rating | V-0 |
| Shrouded | No |
| Grounding | Grounded |
| Key Resistance Properties | Standard Resistance |
| Surge Protection | No |
| Horsepower Rating | 1/2 hp |
| Includes Mounting Hardware | Yes |
| Housing Color | Ivory |
| Grade | Hospital Grade Fed. Spec. |
| Maximum Operating Temperature | 167 Degrees F |
| AFCI | No |
| Minimum Operating Temperature | -40 Degrees F |
| Device Color | Ivory |
| Flammability | UL 94 V-0 |
| Terminal Accommodation | #14-#10 AWG copper stranded or solid conductor only |
| Operating Temperatures | Maximum continuous 75°C; minimum -40°C (w/o impact) |
| Poles and Wires | 2 Pole, 3 Wire |
| Device Grade | Heavy Duty Spec Grade |
| Current Interrupting | Certified for current interrupting at full rated current |
| Terminal Identification | Terminals identified in accordance with UL 498 and CSA |
| Dielectric Voltage | Withstands 2,000V minimum |
| Material - Mounting Hardware | Screw Mounting |
| Environmental Conditions | Indoor Dry Unless Protected By Additional Means |
| Current / Amperage Rating | 15 A |
| Voltage Rating Description | 125 V |
| Horsepower - Maximum | 0.5 |
| Performance | Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - Withstands 2,000V minimum Environmental - Flammability - UL 94 V-0 Environmental - Operating Temperatures - Maximum continuous 75°C, minimum -40°C (w/o impact) Mechanical - Product Identification - Ratings are a permanent part of the device Mechanical - Terminal Accommodation - #14-#10 AWG stranded or solid copper wire only Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA |
| Industry Standard(s) | CSA Certified, C22.2, No. 42 File 285 Fed. Spec. W-C-596 NEMA® WD-6 Compliant UL Listed to UL498 File No. E2186 |
| OEM Brand Name | Hubbell Wiring Device-Kellems |
| Item Type | Traditional Duplex |
| Amperage Rating | 15 A |
