KH Industries CPH04-D1D-000A Pendant Control Station (4) Push Buttons, 1NO, No Legend, NEMA 4/4X
Original price
$437.49
-
Original price
$437.49
Original price
$437.49
$437.49
-
$437.49
Current price
$437.49
Pendant Control Station, Number of Operators 4, Number of Pilot Lights 0, Legend No Legend, Type of Operator Push Button, Action Momentary/Momentary/Momentary/Momentary, Operator Color Yellow, Contact Form 1NO, Mechanical Interlock Yes, NEMA Rating 4X, Contact Rating 0.4A @ 120V DC, 2A @ 24V DC, 5A @ 125/240V AC, IP Rating IP65, Hub 5/16 in to 53/64 in, Height 7.7 in, Width 3.1 in, Depth 1.5 in, Enclosure Material Thermoplastic, Enclosure Color Yellow, Standards cUL, UL Listed
| Contact Form | 1NO |
| Legend | No Legend |
| Type of Operator | Push Button |
| Number of Pilot Lights | 0 |
| Number of Operators | 4 |
| NEMA Rating | 4x |
| Hub Style | Dead-End |
| Housing Color | Yellow |
| Standards | cUL, UL Listed |
| Contact Rating | 0.4A @ 120V DC, 2A @ 24V DC, 5A @ 125/240V AC |
| Action | Momentary/Momentary/Momentary/Momentary |
| Hub | 5/16 in to 53/64 in |
| Mechanical Interlock | Yes |
| Includes | Cable Bushing(s) |
| Housing Material | ABS |
| Number of Speeds | 2 |
| Enclosure Material | Thermoplastic |
| IP Rating | IP65 |
| Switch Type | Buttons 1, 2, 3, 4: Two Speed Momentary with Interlock |
| Operator Color | Yellow |
| Enclosure Color | Yellow |
| Product Type | Pendant Control Station |
| Includes Mechanical Interlock | Mechanical Interlock Included |
| Hazardous Location Specification | Not Rated |
| AC Contact Rating | 5 A @ 125/240 V |
| DC Contact Rating | 0.4 A @ 120 V, 2 A @ 24 V |
| Operator Configuration | (4) Push Buttons |
| Resistance Properties | Corrosion Resistant, Shock Resistant, Vibration Resistant |
| NEMA Enclosure Rating | 4, 4X |
| Cable Bushing | .31-.83 |
| Speed | Two |
