Lincoln 82230 Air Operated Drum Pump 55 gal For Container Size, 20 gpm Max. Flow Rate

Air Operated Drum Pump, Max. Air Pressure 150 psi, Suction Tube Material Steel, Self-Priming Yes, Explosion Proof No, Discharge Connection Type NPT, Features Designed to Stall Against Lubricant Pressure, Use Built in Air Control Valve to Adjust Fluid Output Flow, Food Grade No, Bung Connection Dia. 2 in, Hose Length Not Applicable, Variable Speed No, Includes Discharge Hose No, Includes Suction Tube Yes, Includes Bung Adapter No, Includes Nozzle Yes, Includes Spout Yes, Runs Dry No

Pump Ratio	1:1
Max. Output	20 gpm
Type	Air Operated
For Use With	New Oil Transfer
Output	20.0 gpm
Includes	Elbow, Pump, Pump Cover
Features	Designed to Stall Against Lubricant Pressure, Use Built in Air Control Valve to Adjust Fluid Output Flow
Pump Connection Type	FNPT
Power Source	Air
Discharge Connection Type	NPT
Suction Tube OD	1 15/16 in
Includes Discharge Hose	No
Suction Tube Material	Steel
Min. Fluid Temp.	30 Degrees F
Not Recommended Chemicals	Diesel Fuel, Gear Lube, Grease, Kerosene
Includes Nozzle	Yes
Ratio	1:1
Max. Fluid Temp.	120 Degrees F
Max. Flow Rate	20 gpm
Min. Air Pressure	25 psi
Max. Oil Flow	20 gpm
Compatible Chemicals	Automatic Transmission Fluid, Hydraulic Oils (Petroleum), Hydraulic Oils (Synthetic), Motor Oil
Diesel Exhaust Fluid Compatible	No
Variable Speed	No
Discharge Tube Outlet ID	3/4 in
Includes Bung Adapter	No
Food Grade	No
For Media Type	Automatic Transmission Fluid, Hydraulic Oils (Petroleum), Hydraulic Oils (Synthetic), Motor Oil
Runs Dry	No
For Container Type	Drum
Wetted Materials	Buna-N, Polyurethane, Steel
Pump Connection ID	3/4 in
Seal Material	Buna-N
Includes Suction Tube	Yes
Nozzle Material	Steel
Self-Priming	Yes
Nozzle Operation	Manual
Includes Spout	Yes
Max. Air Pressure	150 psi
Metered	No
Housing Material - Pumps	Aluminum, Steel
Grease	X
Gear Lube	X
Explosion Proof	No
Max. Outlet Pressure	150 psi
