McMaster 23065A674 Plug Gauge Size 0.0750 in, Class Z Plug No-Go Gauge
Original price
$22.59
-
Original price
$22.59
Original price
$22.59
$22.59
-
$22.59
Current price
$22.59
These Class Z no-go gauges help you check the maximum hole diameter. Commonly known as pin gauges, use them to measure hole size and depth, check hole location and distance, and set micrometers. All come with a certificate of accuracy traceable to NIST that states they've passed a test for accuracy.
If a no-go gauge is unable to enter the hole and a go gauge can, the hole is within tolerance.
|
Gauge Type
|
No-Go |
|
Class
|
Z |
|
Plug Gauge Size
|
0.0750" |
|
Choose a Plug Gauge Size
|
0.0610" to 0.2500" |
|
Increment
|
0.0005" |
|
Plug Gauge Tolerance
|
-0.0001" to 0" |
|
Length
|
2" |
|
Surface Smoothness (RMS)
|
8 microinch |
|
Hardness
|
Rockwell C60 |
|
Material
|
Tool Steel |
|
Certification
|
Accuracy Certificate Traceable to NIST |
|
Plug Gauge Size
|
0.0750 in. |
|
RoHS
|
RoHS 3 (2015/863/EU) Compliant |
|
REACH
|
Not Compliant |
|
DFARS
|
Specialty Metals COTS-Exempt |
|
Country of Origin
|
United States |
|
USMCA Qualifying
|
No |
|
Schedule B
|
903180.8080 |
|
ECCN
|
EAR99 |
