McMaster 4452K622 316 Stainless Steel Threaded Pipe Tee Connector, 3 NPT Female, Class 150, Low-Pressure
Original price
$364.40
-
Original price
$364.40
Original price
$364.40
$364.40
-
$364.40
Current price
$364.40
Use these fittings in a low-pressure pipe line.
316 Stainless Steel — Fittings are the most corrosion resistant. They stand up to wet environments, just like 304 stainless steel fittings, but unlike 304 stainless steel, they will not corrode from salt water, chlorine solutions, and chemicals.
ANSI/MSS SP-114 — Fittings that meet ANSI/MSS SP-114 adhere to high-quality standards for heat treating, material thickness, and marking.
| Pressure Rating | Low Pressure |
| Shape | Tee |
| Fitting Type | Connector |
| Fitting Connection | NPT Female |
| Material | 316/316L Stainless Steel |
| Pipe Size | 3" |
| Pressure Class | 150 |
| Maximum Pressure @ Temperature | 300 psi @ 72°F |
| Maximum Steam Pressure @ Temperature | 150 psi @ 350°F |
| Fabrication | Heat Treated |
| For Pipe Schedule | 40 |
| For Use With | Air, Natural Gas, Oil, Steam, Water |
| Performance | Chemical Resistant, Ultra Corrosion Resistant |
| Specifications Met | ANSI/MSS SP-114, ASTM A351 |
| System of Measurement | Inch |
| Country of Origin | China, Vietnam |
| DFARS Compliance | Specialty Metals COTS-Exempt |
| ECCN | 2B999 |
| REACH Compliance | REACH (EC 1907/2006) (06/27/2024, 241 SVHC) Compliant |
| RoHS Compliance | RoHS 3 (2015/863/EU) Compliant |
| Schedule B Number | 7307.22.5000 |
| USMCA Qualifying | No |
