McMaster 44705K922 Low-Pressure 6061 Aluminum Pipe Adapter, 1-1/4 NPT Female x Butt-Weld, Class 150 (sub for 44705K322 — NOT MIL-DTL-52618 certified)
Original price
$49.35
-
Original price
$49.35
Original price
$49.35
$49.35
-
$49.35
Current price
$49.35
In addition to being lightweight, these aluminum fittings offer good corrosion resistance. Use them in low-pressure flow applications. To prevent cracking, do not tighten more than a 1/4-turn past hand tight.
Threaded Fitting Connection — Threaded female x butt weld straight adapters are also known as half couplings.
Note: This is McMaster's suggested substitute for 44705K322 (discontinued). 44705K922 is 31/32" long vs 1" on K322, and does NOT meet MIL-DTL-52618.
| Pressure Rating | Low Pressure |
| Shape | Straight |
| Fitting Type | Adapter |
| Fitting Connection | NPT Female × Butt Weld |
| Pipe Size A | 1 1/4" |
| Pipe Size B | 1 1/4" |
| Pressure Class | 150 |
| Material | 6061 Aluminum |
| Maximum Pressure @ Temperature | 150 psi @ 72°F |
| Length | 31/32" |
| Wall Thickness | 0.234" |
| Threading | Threaded on One End |
| Construction (B) | Welded |
| For Pipe Schedule | 40 |
| For Use With | Air, Oil, Water |
| Performance | Corrosion Resistant |
| Specifications Met | ASME B1.20.1, ASTM A865, ASTM B221 |
| System of Measurement | Inch |
| Country of Origin | United States |
| DFARS Compliance | Specialty Metals COTS-Exempt |
| ECCN | EAR99 |
| REACH Compliance | REACH (EC 1907/2006) (02/04/2026, 253 SVHC) Compliant |
| RoHS Compliance | RoHS 3 (2015/863/EU) Compliant |
| Schedule B Number | 7609.00.0000 |
| USMCA Qualifying | Yes |
