McMaster 4620K24 Inline Hydraulic Check Valve, 3/4 NPTF Female Inlet, Brass Body, 20 gpm Maximum Flow Rate
Original price
$180.47
-
Original price
$180.47
Original price
$180.47
$180.47
-
$180.47
Current price
$180.47
Hydraulic check valves open to allow flow in one direction and close when flow stops or reverses.
NPTF Thread—NPTF (Dryseal) threads are compatible with NPT threads.
Brass Body—Brass valves have good corrosion resistance.
| Inlet Connection | |
| Pipe Size | 3/4 |
| Thread Type | NPTF |
| Gender | Female |
| Dash Size | 12 |
| Number of Ports | 1 |
| Outlet Connection | |
| Pipe Size | 3/4 |
| Thread Type | NPTF |
| Gender | Female |
| Dash Size | 12 |
| Number of Ports | 1 |
| Check Valve Type | Ball |
| Body Material | Brass |
| Maximum Flow Rate | 20 gpm |
| Flow Coefficient (Cv) | 5.41 |
| Maximum Pressure | 2,000 psi |
| Minimum Opening Pressure | 2.5 psi |
| Port-to-Port Length | 3 1/4" |
| Hex Width | 1 3/8" |
| Mounting Position | Any Angle |
| Temperature Range | -30° F to 200° F |
| Actuation | Pressure |
| For Use With | Hydraulic Fluid |
| Return Actuation | Spring |
| Total Number of Ports | 2 |
| Valve Function | Backflow Prevention |
| Valve Type | Check |
| Country of Origin | United States |
| DFARS Compliance | Specialty Metals COTS-Exempt |
| ECCN | EAR99 |
| REACH Compliance | Not Compliant |
| RoHS Compliance | RoHS 3 (2015/863/EU) Compliant with Exemptions |
| RoHS Exemptions | 6(c) |
| Schedule B Number | 848130.1090 |
| USMCA Qualifying | No |
