McMaster 47885K78 316 Stainless Steel Check Valve, for Steam, 2 NPT Female, 81 Cv
Original price
$1,843.60
-
Original price
$1,843.60
Original price
$1,843.60
$1,843.60
-
$1,843.60
Current price
$1,843.60
To withstand high pressures and temperatures in steam service applications, these valves have a 316 stainless steel body, PTFE ball, and PTFE seal. They open to allow flow in one direction and close when flow stops or reverses.
Flow Coefficient (Cv) — Flow coefficient (Cv) is the amount of water (in gallons per minute) at 60° F that will flow through a fully open valve with a difference of 1 psi between the inlet and the outlet.
Warning: Chemical compatibility must be determined by the customer based on the conditions in which the product is being used, including the presence of other chemicals, temperature, and consistency.
| Body Material | 316 Stainless Steel |
| Check Valve Type | Spring-Loaded Ball |
| Inlet Connection | Threaded, NPT Female, Connects to Pipe |
| Outlet Connection | Threaded, NPT Female, Connects to Pipe |
| Pipe Size | 2 |
| Flow Coefficient (Cv) | 81 |
| Maximum Steam Pressure @ Temperature | 125 psi @ 350° F |
| Minimum Opening Pressure | 0.5 psi |
| Temperature Range | -5° F to 350° F |
| End-to-End Length | 6" |
| Mounting Position | Horizontal, Vertical |
| For Use With | Steam |
| Ball Material | PTFE |
| Spring Material | 316 Stainless Steel |
| Seal Material | PTFE |
| Actuation | Pressure |
| Chemical Resistance (Excellent) | Steam |
| Fitting Type | Connector |
| Shape | Straight |
| Valve Function | Backflow Prevention |
| Valve Type | Check |
| Country of Origin | United States |
| DFARS Compliance | Specialty Metals COTS-Exempt |
| ECCN | 2B999 |
| REACH Compliance | REACH (EC 1907/2006) (01/21/2025, 247 SVHC) Compliant |
| RoHS Compliance | RoHS 3 (2015/863/EU) Compliant |
| Schedule B Number | 8481.30.2090 |
| USMCA Qualifying | Yes |
