McMaster 51205K619 Extreme-Pressure 316 Stainless Steel Pipe Fitting Straight Reducer, 1 x 1/4 NPT Female
Original price
$133.36
-
Original price
$133.36
Original price
$133.36
$133.36
-
$133.36
Current price
$133.36
McMaster 51205K619 Extreme-Pressure 316 Stainless Steel Pipe Fitting Straight Reducer, 1 x 1/4 NPT Female
With the strength to handle extreme pressures, these fittings can be used to connect equipment in hydraulic fluid lines. 316 stainless steel fittings have excellent corrosion resistance.
|
Shape
|
Straight |
|
Type
|
Reducer |
|
Body Shape
|
Hex |
|
Material
|
316 Stainless Steel |
|
Fabrication
|
Machined |
|
Connection Type
|
Pipe |
|
Connection Style
|
Threaded |
|
Connection
|
NPT Female |
|
Pipe Size
|
|
|
(A)
|
1 |
|
(B)
|
1/4 |
|
Dash Size
|
|
|
(A)
|
16 |
|
(B)
|
04 |
|
Length
|
1 49/64" |
|
Hex Width
|
1 5/8" |
|
Maximum Pressure
|
3,000 psi @ 72° F |
|
Maximum Steam Pressure
|
3,000 psi @ 200° F |
|
For Use With
|
Hydraulic Fluid, Oil, Steam, Water |
|
Specifications Met
|
SAE J514 |
|
RoHS
|
RoHS 3 (2015/863/EU) Compliant |
|
REACH
|
Not Compliant |
|
DFARS
|
Specialty Metals COTS-Exempt |
|
Country of Origin
|
United States |
|
USMCA Qualifying
|
No |
|
Schedule B
|
730729.0000 |
|
ECCN
|
2B999 |
