McMaster 6384K77 Steel Ball Bearing, Sealed, Trade No. 3028-2RS, for 5/8" Shaft Diameter, 1300 lb
Original price
$83.80
-
Original price
$83.80
Original price
$83.80
$83.80
-
$83.80
Current price
$83.80
Smoother than smooth—the balls inside these bearings roll nearly friction-free. You’ll often find them on rapidly rotating parts, from the whirring chuck on a power drill to the spinning shaft on an electric motor.
Sealed — The best choice for dirty environments. A barrier seals out dust so it won't gunk up or wear down the balls. However, these bearings retain the most heat since air can't flow through.
Steel — Strong and wear resistant. However, these bearings are best for dry environments since moisture will cause them to rust.
| For Shaft Type | Round |
| Bearing Seal Type | Sealed |
| Material | Steel |
| For Shaft Diameter | 5/8" |
| For Housing ID | 1 5/8" |
| Width | 1/2" |
| Dynamic Radial Load Capacity | 1,300 lb. |
| Static Radial Load Capacity | 1,000 lb. |
| Maximum Rotation Speed | 2,500 rpm |
| Temperature Range | -20° to 250° F |
| Bearing Trade Number | 3028-2RS |
| Ball Material | Steel |
| Bearing Construction | Single Row |
| Bearing Type | Ball |
| Cage Material | Nylon |
| For Load Direction | Radial |
| ID | 0.625" |
| OD | 1.625" |
| Radial Clearance | 0.001" to 0.005" |
| Seal Material | Buna-N |
| Shaft Mount Type | Press Fit |
| Lubricant | Grease |
| System of Measurement | Inch |
| Country of Origin | United States |
| DFARS Compliance | Specialty Metals COTS-Exempt |
| ECCN | 1C999 |
| REACH Compliance | Not Compliant |
| RoHS Compliance | RoHS 3 (2015/863/EU) Compliant |
| Schedule B Number | 8482.10.5048 |
| USMCA Qualifying | Yes |
