McMaster 7871A11 Multicheck Weld Inspection Gauge
Original price
$170.15
-
Original price
$170.15
Original price
$170.15
$170.15
-
$170.15
Current price
$170.15
Check bevel angles, excess weld metal (capping size), length of a corner-weld leg, throat length, and depth of undercut.
|
Welding Process
|
MIG, Oxyacetylene, Stick, TIG |
|
Bevel Angle Measured
|
0°-60° |
|
Excess Weld Metal (Capping Size)
|
|
|
Maximum Size Measured
|
1", 25 mm |
|
Graduation Marks
|
1/16", 1 mm |
|
Corner-Weld Leg Length
|
|
|
Maximum Length Measured
|
1", 25mm |
|
Graduation Marks
|
1/16", 1 mm |
|
Throat Length
|
|
|
Maximum Length Measured
|
3/4", 20mm |
|
Graduation Marks
|
1/16", 1 mm |
|
Depth of Undercut
|
|
|
Maximum Size Measured
|
3/16", 5 mm |
|
Graduation Marks
|
1/16", 1 mm |
|
Material
|
Stainless Steel |
|
Includes
|
Vinyl Carrying Case |
|
RoHS
|
Not Compliant |
|
REACH
|
Not Compliant |
|
DFARS
|
Specialty Metals COTS-Exempt |
|
Country of Origin
|
Taiwan |
|
Schedule B
|
901730.8000 |
|
ECCN
|
EAR99 |
