MKT Fastening M14515301 Wedge Anchor Bolt 152 mm Overall Lg, 24 mm Dia, M16 Thread Size, Steel, Steel, 2 PK
Original price
$90.45
-
Original price
$90.45
Original price
$90.45
$90.45
-
$90.45
Current price
$90.45
Wedge Anchor Bolt, System of Measurement Metric, Anchor Diameter 24 mm, Thread Size M16, Overall Length 152 mm, Thread Length Not Applicable, Eyelet Hole Size Not Applicable, Material Steel, Material Grade/Class Class 8.8, Finish Zinc Plated, Compatible Material Concrete, Drill Bit Size 24 mm, Minimum Installation Depth 120 mm, Minimum Material Thickness 203 13/64 mm, Ultimate Shear Strength (4,000 psi Concrete) 38,920 lb, Ultimate Tension Strength (4,000 psi Concrete) 14,057 lb, Nut Width 24 mm
| Compatible Material | Concrete |
| Sub-Brand | SZ-S |
| Material | Steel |
| Finish | Zinc Plated |
| Seismic Approved | Yes |
| ICC Approved for Cracked Concrete | Yes |
| Ultimate Shear Strength (4,000 psi Concrete) | 38,920 lb |
| Ultimate Tension Strength (4,000 psi Concrete) | 14,057 lb |
| Allowable Tension in 2500 PSI Uncracked Concrete (Lbs.) | 4352 |
| Allowable Shear in 2500 PSI Uncracked Concrete (Lbs.) | 6640 |
| Allowable Tension in 6500 PSI Uncracked Concrete (Lbs.) | 6743 |
| Allowable Tension in 2500 PSI Cracked Concrete (Lbs.) | 3083 |
| Material Grade | Class 8.8 |
| Allowable Tension in 6500 PSI Cracked Concrete (Lbs.) | 4776 |
| Allowable Shear in 2500 PSI Cracked Concrete (Lbs.) | 6640 |
| Allowable Shear in 6500 PSI Uncracked Concrete (Lbs.) | 9519 |
| Allowable Shear in 6500 PSI Cracked Concrete (Lbs.) | 9519 |
| ICC Approved for Un-Cracked Concrete | Yes |
| Industry Standards | ICC ESR-3173 |
| Wedge Anchor Type | Seismic Wedge Anchor |
| Minimum Ultimate Shear Strength | 5,620 lb |
| Maximum Installation Torque | 118 ft-lb |
| Series | SZ-S |
| Maximum Ultimate Shear Strength | 44,623 lb |
| Minimum Ultimate Tension Strength | 3,765 lb |
| Material Grade/Class | Class 8.8 |
| Minimum Installation Torque | 118 ft-lb |
| Material Quality Standards | ACI 318 Category 1 |
| System of Measurement | Metric |
| Maximum Ultimate Tension Strength | 21,444 lb |
| Removable | Removable |
| Manufacturer Location | Made in USA |
