PBC Linear LSR0601T-0200-VCF-080-NNN-N Motorized Lead Screw Assembly, NEMA 8 Stepper Motor, 6 mm Screw Dia, 1 mm Lead, 200 mm Lg
Original price
$448.61
-
Original price
$448.61
Original price
$448.61
$448.61
-
$448.61
Current price
$448.61
Precision Lead Screw, Nut Type Anti-Backlash, Coating Material PTFE, Screw Material Stainless Steel, Screw Material Grade 300, Frame NEMA 8, Nut Shape Rectangle, Insulation Class B, Screw Diameter 6 mm, Lead Length 1 mm, Screw Length 200 mm, Nut Length 22.2 mm, Nut Flange Diameter 17.8 mm, Motor Length 29.5 mm, Rated Current 0.4 A, Steps per Revolution 200, Motor IP Rating IP40, Phase 2, Motor Maximum Operating Temperature 50 Degrees C, Motor Minimum Operating Temperature -20 Degrees C
| Nut Drag Torque | 0.0134 to 0.0164 Nm |
|---|---|
| Thread Direction | Right |
| Phase | 2 |
| Screw Material Grade | 300 |
| Coating Material | PTFE |
| Screw Material | Stainless Steel |
| Electrical Connection | Plug-In Connector |
| Motor IP Rating | IP40 |
| Assembly Type | Lead Screw Assembly |
| Rated Current | 0.4 A |
| Step Accuracy | +/-5% |
| Insulation Class | B |
| Motor Minimum Operating Temperature | -20 Degrees C |
| Motor Maximum Operating Temperature | 50 Degrees C |
| Nut Shape | Rectangle |
| Screw Type | Lead Screw |
| Right End Components | None |
| Travel per Step | 0.005 in |
| Motor Type | Stepper Motor |
| Nut Material | Stainless Steel |
| Steps per Revolution | 200 |
| Frame | NEMA 8 |
| Lead Accuracy | 0.003 in/ft |
| Insulation Resistance | 100 Mohm |
| Nut Type | Anti-Backlash |
| Winding Resistance | 13.9 ohm |
| Left End Components | None |
| Percent Efficiency | 39% |
| Nut Dynamic Load Capacity | 302 N |
| Country of Origin | United States |
