PBC Linear VRSD4-025.000 Drilled Linear Rail, V-Guide, Size 4, 25 in Length, 0.437 in Width, Stainless Steel
Original price
$208.57
-
Original price
$208.57
Original price
$208.57
$208.57
-
$208.57
Current price
$208.57
Drilled Linear Rail, Overall Length 25 in, Overall Width 0.437 in, Overall Height 1.037 in, Rail Material Stainless Steel, Manufacturer Size 4, Number of Mounting Holes 7, Rail Finish Cold Roll, Rail Type Slide, System of Measurement Inch, For Use With V-Guide Wheels and Bushings, Operating Temperature - Maximum 180 Degrees F, Operating Temperature - Minimum 0 Degrees F, Mounting Hole Center to Center 4 in, Mounting Hole Center to Shaft End 2.5 in, Channel Material Stainless Steel
| Type | V-Guide |
|---|---|
| Rail Material | Stainless Steel |
| Manufacturer Size | 4 |
| Overall Length | 25 in |
| Overall Width | 0.437 in |
| Overall Height | 1.037 in |
| Mounting Hole Size | 0.344 in |
| Thread Size | 0.312 in or M8 |
| Undercut Depth | 0.314 in |
| Temp. Range (F) | 0 - 248 |
| Screw Type | Low Profile Socket Head Cap |
| For Use With | V-Guide Wheels and Bushings |
| Rail Finish | Cold Roll |
| Mounting Hole from Shaft End | 0.5 in |
| Raceway | 303 Stainless Steel |
| Mounting Hole Center to Center | 4 in |
| Number of Rail Holes | 7 |
| Number of Mounting Holes | 7 |
| Raceway Material | 303 Stainless Steel |
| Rail Type | Slide |
| Maximum Operating Temperature | 248 Degrees F |
| Series | V-Guide |
| Minimum Operating Temperature | 0 Degrees F |
| Mounting Hole Center to Shaft End | 2.5 in |
| Requires Lubrication | Lubricant Not Required |
| Edge Angle | 90 Degrees |
| Load Direction | Axial, Radial |
| Channel Material | Stainless Steel |
| System of Measurement | Inch |
| Country of Origin | United States |
