Pemko CFS95CP-HD1-HT-RH Heavy Duty Continuous (Piano) Hinge, Bronze, 95 in, Full Surface Center Pivot, Right Hand, Hospital Tip, Grade 1, 540 lb Cap, UL10C
Original price
$547.03
-
Original price
$547.03
Original price
$547.03
$547.03
-
$547.03
Current price
$547.03
Pemko CFS95CP-HD1-HT-RH heavy duty Grade 1 continuous (piano) hinge, bronze material with Clear Anodized / Satin Aluminum finish. 95 in length, 83 in frame leaf height, 95 in door leaf height. 1-1/4 in frame leaf width, 1-3/8 in door leaf width, 0.125 in leaf thickness, 2 in knuckle height, 2-7/8 in overall width. Full Surface Center Pivot mounting, Right Hand orientation, Hospital Tip pin, geared hinge. 540 lb load capacity, 180° range of motion, UL10C fire rated, ANSI/BHMA A156.26. 12 holes per leaf, hardware included. Ligature resistant.
| Brand | Pemko |
| Material | Bronze |
| Finish | Satin Aluminum, Clear Anodized |
| Frame Leaf Width | 1-1/4 in |
| Door Leaf Width | 1-3/8 in |
| Overall Height | 83 in |
| Length | 95 in |
| Door Leaf Height | 95 in |
| Frame Leaf Thickness | 0.125 in |
| Door Leaf Thickness | 0.125 in |
| Overall Width | 2-7/8 in |
| Overall Knuckle Height | 2 in |
| Number of Holes per Leaf | 12 |
| Load Capacity | 540 lb |
| Range of Motion - Maximum | 180 Degrees |
| Pin Material | Geared |
| Pin Type | Hospital Tip |
| Mounting | Full Surface Center Pivot |
| Hand Orientation | Right Hand |
| Includes Hardware | Hardware Included |
| Standards | ANSI/BHMA A156.26; UL Certified |
| UL Fire Rating | UL10C |
| Fire Rating | 3 hr |
| Ligature Resistant | Yes |
| Features | Hospital Tip; Heavy Duty, Grade 1 |
