Redhat 8342G003 Solenoid Valve, 4-Way, 3/8 in Pipe Size, 120V AC, Watertight/Without Junction Box, Brass Body
Original price
$628.01
-
Original price
$628.01
Original price
$628.01
$628.01
-
$628.01
Current price
$628.01
| For Media | Air; Inert Gases; Light Oil; Water |
|---|---|
| Application | Analytical and Diagnostic Equipment; Biofuel and Heating Systems; Dust Collector Systems; Heating Equipment; Refining Applications |
| Valve Type | NAMUR Mount |
| Mounting Orientation | Horizontal or Vertical |
| Operation Type | Direct Acting |
| Valve Ways | 4-Way |
| Valve Positions | 2-Position |
| Body Material | Brass |
| Seal Material | NBR |
| Nominal Pipe Size | 3/8 in |
| Inlet Connection Type | NPTF |
| Outlet Connection Type | NPTF |
| Voltage | 120V AC |
| Wattage | 20.1 W |
| Frequency | 60 Hz |
| Electrical Connections | 1/2" Conduit w/18" Leads |
| Coefficient of Volume (Cv) | 0.7 |
| Orifice Diameter | 3/16 in |
| Min. Operating Pressure Differential | 0 psi |
| Max. Operating Pressure Differential - Water | 100 psi |
| Max. Operating Pressure Differential - Steam | Not Rated |
| Max. Operating Pressure Differential - Light Oil | 100 psi |
| Max. Operating Pressure Differential - Air/Inert Gas | 125 psi |
| Max. Fluid Temperature | 160 °F |
| Min. Ambient Temperature | 32 °F |
| Max. Ambient Temperature | 125 °F |
| Includes Seal | Yes |
| Includes Coil | Yes |
| Coil Enclosure | Watertight; Without Junction Box |
| Coil Insulation Class | F |
| Overall Height | 4-7/16 in |
| Overall Length | 2-15/16 in |
| Overall Width | 2-9/16 in |
| Operating Environment | Indoor; Outdoor |
| IP Rating | IP66 |
| NEMA Rating | 1; 2; 3; 3S; 4; 4X |
| Standards | CSA; UL Listed |
| Country of Origin | USA |
