SKF NU 216 ECJ/C3 Cylindrical Roller Bearing, 216, 80 mm Bore, 140 mm OD, 26 mm Overall Wd, Steel, NU 216 ECJ/C3
UPC: | Harmonization / Schedule B : 8482.50.0000
Country of Origin: | Shipping Weight: 3.507 lbs
Original price
$600.31
-
Original price
$600.31
Original price
$600.31
$600.31
-
$600.31
Current price
$600.31
Cylindrical Roller Bearing, Bearing Industry Number 216, Bore Diameter 80 mm, Bore Type Cylindrical, Cage Material Steel, Closure Open, Inner Ring Outside Diameter 121.691 mm, Maximum Speed 5,600 RPM, Maximum Temperature 300 Degrees F, Minimum Temperature -40 Degrees F, Number of Rows One, Outer Ring Inside Diameter 122 mm, Outside Diameter 140 mm, Overall Width 26 mm, Ring Material Alloy Steel, Roller Material Steel, Split Bearing Yes, System of Measurement Metric
| Bore Dia. | 80 mm |
|---|---|
| Outside Dia. | 140 |
| Width | 26 mm |
| Outside Dia. Tolerance | +0/-.018mm |
| Inner Ring Outside Dia. (In.) | 3.976 in |
| Shoulder Height (mm) | 129 mm |
| Outer Ring Inside Dia. (mm) | 123 mm |
| Outer Ring Inside Dia. (In.) | 4.8425 in |
| Inner Ring Outside Dia. (mm) | 101 mm |
| Shoulder Height (In.) | 5.0787 in |
| Shaft Fillet Radius | 2 mm |
| Outside Diameter Tolerance | +0.000/-0.018 mm |
| Overall Width | 26 mm |
| Bore Diameter Tolerance | +0.000/-0.015 mm |
| Bore Diameter | 80 mm |
| Housing Fillet Radius | 2 mm |
| Inner Ring Outside Diameter | 121.691 mm |
| Outer Ring Inside Diameter | 122 mm |
| Outside Diameter | 140 mm |
| MFR # | NU 216 ECJ/C3 |
| Zoro # | G7908713 |
| UPC # | - |
| Country of Origin | Multiple |
| Roller Material | Steel |
| Cage Material | Steel |
| Static Load Capacity (Lb.) | 37,300 lb |
| Dynamic Load Capacity (Lb.) | 36,000 lb |
| Fillet Radii (In.) | 0.0787 in |
| Type | Open |
| Temp. Range (F) | -40 Degrees to 300 Degrees F |
| Fillet Radii (mm) | 2 mm |
| Tolerance | +0/-.015mm |
| Static Radial Load Capacity | 166 kN |
| Maximum Temperature | 300 Degrees F |
| Split Bearing | Yes |
| Full Complement | No |
| Dynamic Radial Load Capacity | 160 kN |
| Number of Outer Ring Flanges | 2 |
| Bearing Industry Number | 216 |
| Number of Inner Ring Flanges | 0 |
| Number of Rows | One |
| System of Measurement | Metric |
| Bore Type | Cylindrical |
| Ring Material | Alloy Steel |
| Minimum Temperature | -40 Degrees F |
| Maximum Speed | 5,600 RPM |
| Includes Retaining Ring | No |
| Closure | Open |
| Ring Material Grade | 100Cr6 |
| Industry Number | 216 |
| Country of Origin | Varies (subject to change) |
