Square D BDA160401 Molded Case Circuit Breaker 40 A Amps, 25kA at 277/408V AC, Fixed, A, 1 Poles, 240V AC

Molded Case Circuit Breaker, 40 A Amps, AC Voltage Rating 240V AC, Max. AIR Rating 25kA at 277/408V AC, For Use With Electrical Distribution Equipment, Industrial Control Panels, Series BDA, Circuit Breaker Type Standard, Number of Poles 1, DC Voltage Rating Not Rated, Terminal Connection Al Mechanical Lug OFF End, I-Line ON End, Trip Type Thermal Magnetic, Phase Single, Instantaneous Trip Fixed, Phase Connection A, Frame Size 125A/BD, Circuit Breaker Mounting Style I-Line, Height 5.39 in

Series	BDA
Amps	40A
Number of Poles	1
AC Voltage Rating	347/600V AC
Circuit Breaker Type	Standard
Phase	1
Circuit Breaker Actuator	Toggle
Circuit Breaker Mounting Style	I-Line
Max. AIR Rating	25kA at 240V AC
Trip Type	Thermal Magnetic
Instantaneous Trip	Fixed
Terminal Connection	I-Line, Lug
Phase Connection	A
DC Voltage Rating	125V DC
Curve Type	B
For Use With	Electrical Distribution Equipment, Industrial Control Panels
Standards	CSA C22.2 No 5, EN/IEC 60947-2, EN/IEC 60947-5-1, GB 14048.2, NEMA AB1, NMX J-266, UL 489
Interrupt Rating	25 kA at 208Y/120/220/240V AC, 18 kA at 480Y/277V AC, 14 kA at 125V DC, 10 kA at 600/347V AC
Features	Mercury Free; PVC Free
Color	Gray
Application	HACR rated Applications; Distribution
Max. Operating Temp.	158 Degrees F
Min. Operating Temp.	-13 Degrees F
Mounting	I-Line
