Telemecanique Sensors 9007TUB1 Severe Duty Limit Switch, Rotary Head No Lever, SPDT, 20A at 600V AC, Side Actuator

Telemecanique Sensors 9007TUB1 Severe Duty Limit Switch, Rotary Head No Lever, SPDT, 20A at 600V AC, Side Actuator

$575.81 - $575.81
$575.81
$575.81 - $575.81
$575.81

Limit Switch, Actuator Style No Lever Rotary, Actuator Location Side, AC Contact Rating 20A @ 600V, DC Contact Rating 20A @ 600V, Contact Form SPDT, Body Height 4.66 in, Body Width 2.25 in, Body Depth 2.44 in, Body Style Standard, NEMA Rating 1, 12, 13, 2, 4, Mounting Surface

Limit Switch Style Severe Duty Limit Switch
Action Maintained
Series 9007T
Actuator Style Rotary Head, No Lever
Includes Actuator No Actuator Included
Actuator Location Side
Contact Form SPDT
Number of Poles 1
Voltage Rating 600VAC/DC
Amps 20
AC Contact Rating 12.5 A @ 240 V, 20 A @ 120 V, 5 A @ 600 V, 6.25 A @ 480 V
DC Contact Rating 0.2 A @ 600 V, 1 A @ 250 V, 5 A @ 120 V
Contact Material Silver flashed copper
Contact Action Snap action
Body Style Standard
Body Material Zinc
IP Rating IP67
NEMA Enclosure Rating 1, 12, 13, 2, 4
Standards NEMA
Wiring Entry 1/2 in NPT
Electrical Connection Screw Clamp Terminals
Mounting Surface
Number of Mounting Holes 4
Mounting Hole Spacing 4.22 in x 1.81 in
Operating Torque - Maximum 12 in-lb
Total Travel 88 Degrees
Pretravel 14 Degrees
Directional Movement CW
Operating Temperature Range -10°F to 185°F
Shock Resistance 30 gn 9 ms IEC 60068-2-27
Vibration Resistance 10 gn 10-55 Hz IEC 60068-2-6
Short Circuit Protection 20 A Bussmann class CC KTK-R-21 fuse non-time delay
Weight 2.5 lb
Country of Origin Mexico
