Wika 113.13.25.60.L Commercial Pressure Gauge Liquid-Filled, 0 to 60 psi (0 to 410 kPa), 2 1/2 in Dial, Bottom
Original price
$33.16
-
Original price
$33.16
Original price
$33.16
$33.16
-
$33.16
Current price
$33.16
Commercial Pressure Gauge, Nominal Dial Size 2 1/2 in, Accuracy +/-3-2-3 Percent, Gauge Case Material ABS, Process Connection Type NPT, Process Connection Gender Male, Lens Material Plastic, Process Connection Size 1/4 in, Field Fillable No, Process Connection Location Bottom, Case Color Black, IP/NEMA Rating IP65, Primary Pressure Range 0 to 60, Dry Dampening Feature None, Vibration Resistance Liquid-Filled, Dial Color White, Pressure Gauge Type General Purpose Dial Pressure Gauge
| Accuracy | +/-3-2-3% |
| Process Connection Location | Bottom |
| Process Connection Type | NPT |
| Application | Compressors, Hydraulics, Marine, Pumps |
| Gauge Case Material | ABS |
| Series | 113.13 |
| Lens Material | Plastic |
| Primary Pressure Range | 0 to 60 psi |
| Primary Scale Units | psi |
| IP/NEMA Rating | IP65 |
| Liquid-Filled Case | Yes |
| Hazardous Location Rating | Not Rated |
| Panel-Mountable | No |
| Blowout Safety Back | No |
| Calibration Certificate Included | No |
| Graduations | 20 psi |
| Gauge Filled With | Glycerin |
| Case Color | Black |
| Gauge Primary Range Numbered Graduations | 10 |
| Gauge Special Options | Heavy Duty |
| For Use With | Brass, Industrial Applications, Media Compatible with Copper Alloy |
| Smallest Graduation | 2 psi |
| Gauge Secondary Range Values | 0 to 60 |
| Gauge Primary Range Smallest Graduation | 10 |
| Characteristics | With Brass Internals |
| Gauge Application | General-Purpose Case |
| Includes | Vent Plug |
| Socket Material | Brass |
| Connection Type | MNPT |
| Standards | EN 837-1 |
| Compatible Process Media | Liquids and Gases |
| Ambient Operating Temperature Range | -4 Degrees to 140 Degrees F (-20 Degrees to 60 Degrees C) |
| Primary Scale Minor Graduations | 10 |
| Pressure Gauge Type | General Purpose Dial Pressure Gauge |
| Pressure Range Type | Pressure |
| Dial Face Material | ABS |
| Dial Color | White |
| Accuracy Scale | Mid-Scale |
| Sensor Type | Bourdon Tube |
| Process Connection Gender | Male |
| Gauge Case Liquid | Glycerin |
| Dry Dampening Feature | None |
| Pointer Material | ABS |
| Accuracy Grade | ASME B40.100 Grade B |
| Sensor Material | Bronze |
| Secondary Scale Units | kPa |
| Freeze Resistant Movement | No |
| Includes Vent Plug | Yes |
| Vibration Resistance | Liquid-Filled |
| Non-Sparking | No |
| Field Fillable | No |
| Includes Calibration Certificate | No |
| Primary Scale Numeric Increments | 10 |
| Pointer Color | Black |
| Secondary Pressure Range | 0 to 410 kPa |
| Includes Mounting Hardware | No |
| Removable Bezel | No |
| Scale Type | Dual |
| Case Construction | Welded Joint |
| Cleaned for Oxygen Service | No |
| Maximum Pressure | 60 |
| Operating Temperature Range | -4 Degrees to 140 Degrees F |
