Honeywell LSA1A Plug-In Limit Switch Roller Lever, Metallic, Momentary, Plug-In, HDLS, Screw Terminals

Plug-In Limit Switch, Actuator Style - Limit Switch No Lever, Rotary, Actuator Location - Limit Switch Side, AC Contact Rating - Limit Switch 10A @ 600V, DC Contact Rating - Limit Switch 10A @ 250V, Contact Form- Switches 1NC/1NO, Body Height - Limit Switch 2.95 in, Body Width - Limit Switch 1.62 in, Body Depth - Limit Switch 1.75 in, Boot Sealed Actuator - Limit Switch No, Body Style - Limit Switch Miniature, NEMA Rating 1, 12, 13, 3, 4, 4X, 6, 6P, Mounting - Limit Switch Surface

Basic Actuator Style - Limit Switch	Rotary
Actuator Style - Limit Switch	No Lever, Rotary
Contact Form- Switches	1NC/1NO
Actuator Location - Limit Switch	Side
AC Contact Rating - Limit Switch	10A at 600V
DC Contact Rating - Limit Switch	10A at 250V
Body Style - Limit Switch	Miniature
Mounting - Limit Switch	Surface
Contact Form - Limit Switch	1NC/1NO
Body Style (Limit Switch)	Miniature
Mounting Hole Spacing - Limit Switch	2.34 in x 1.16 in
Actuator Style (Limit Switch)	Rotary, No Lever
Basic Actuator Style (Limit Switch)	Rotary
IP Rating	65, 66, 67
Boot Sealed Actuator (Limit Switch)	No
Travel	Differential Travel 5 Degrees , Maximum Pretravel 15 Degrees , Minimum Over Travel 60 Degrees
AC Contact Rating	10A at 600V
Operating Temp. Range	10 Degrees to 250 Degrees F
Operating Force	4.0 in-lb
DC Contact Rating	10A at 250V
Wiring Entry	1/2"-14 NPT
Body Material	Zinc Die Cast
Contact Form	1NC/1NO, SPDT
Actuator Location (Limit Switch)	Side
Electrical Connection	Screw Terminals
Amps	10
Standards	CCC, CE, CSA, UL
Actuator Style	Rotary Head, No Lever
Limit Switch Style	Heavy Duty Limit Switch
Voltage Rating	600VAC/250VDC
Boot Sealed Actuator - Limit Switch	No
Movement	CCW, CW
Series	LSA
Actuator Location	Side
Mounting Hole Pattern - Limit Switch	2 Hole Diagonal
Stem Thread - Limit Switch	No Stem
Number of Poles	1
Mounting Hole - Limit Switch	(2) 0.20 in dia
NEMA Rating	1, 12, 13, 3, 4, 4X, 6, 6P
Differential Travel	5 Degrees
Operating Temperature - Maximum	250 Degrees F
Number of Mounting Holes	2
NEMA Enclosure Rating	1, 12, 13, 3, 4, 4X, 6, 6P
Operating Temperature - Minimum	10 Degrees F
Mounting Hole Horizontal Center to Center Distance	60 mm
Mounting Style	Surface
Action	Momentary
Includes Actuator	No Actuator Included
Operating Torque - Maximum	4 in-lb
Mounting Hole Vertical Center to Center Distance	30 mm
Overtravel	60 Degrees
Boot Sealed Actuator	No Boot Included
Pretravel	15 Degrees
Resistance Properties	Corrosion Resistant
Directional Movement	CCW/CW
Body Configuration	Plug-In
