Square D QO230 Miniature Circuit Breaker 30 A, 120/240V AC, Single Phase, 10kA at 120/240V AC, QO, Std
Square D QO230 Miniature Circuit Breaker 30 A, 120/240V AC, Single Phase, 10kA at 120/240V AC, QO, Std
Square D QO230 Miniature Circuit Breaker 30 A, 120/240V AC, Single Phase, 10kA at 120/240V AC, QO, Std
Square D QO230 Miniature Circuit Breaker 30 A, 120/240V AC, Single Phase, 10kA at 120/240V AC, QO, Std
Square D QO230 Miniature Circuit Breaker 30 A, 120/240V AC, Single Phase, 10kA at 120/240V AC, QO, Std
Square D QO230 Miniature Circuit Breaker 30 A, 120/240V AC, Single Phase, 10kA at 120/240V AC, QO, Std
Square D QO230 Miniature Circuit Breaker 30 A, 120/240V AC, Single Phase, 10kA at 120/240V AC, QO, Std
Square D QO230 Miniature Circuit Breaker 30 A, 120/240V AC, Single Phase, 10kA at 120/240V AC, QO, Std

Square D QO230 Miniature Circuit Breaker 30 A, 120/240V AC, Single Phase, 10kA at 120/240V AC, QO, Std

$68.39 - $68.39
$68.39
$68.39 - $68.39
$68.39
Miniature Circuit Breaker, Amps 30 A, AC Voltage Rating 120/240V AC, Circuit Breaker Type Standard, Number of Poles 2, DC Voltage Rating 48V DC, Circuit Breaker Actuator Paddle, Circuit Breaker Mounting Style Plug In, Compatible Panelboard/Load Center Series QO, Phase Single, Series QO, Max. AIR Rating 10kA at 120/240V AC, For Use With QO Load Centers and NQ Panelboards, Terminal Connection Pressure plate, Frame Size 100A/QO, Length 3 in, Width 1.5 in, Depth 2.91 in
Series QO
Amps 30A
Number of Poles 2
AC Voltage Rating 120/240V AC
Circuit Breaker Type Standard
Phase 1
Circuit Breaker Actuator Paddle
Circuit Breaker Mounting Style Plug In
Max. AIR Rating 10kA at 120/240V AC
Terminal Connection Pressure plate
DC Voltage Rating 48V DC
Standards CSA Certified, HACR, UL Listed
For Use With QO Load Centers and NQ Panelboards
Features Mercury Free
Application HACR rated Applications
Interrupt Rating 10 kA at 120/240V AC
Min. Operating Temp. 104 Degrees F
Compatible Panelboard/Load Center Series QO
Max. Operating Temp. 104 Degrees F
Certifications UL Listed; CSA
Ratings HACR rated
Tightening Torque 35.40 lbf.in (4 N.m)
Ambient Temperature Rating 104°F (40°C)
